960 Series Lug & Ring Terminal Insulator

Multiple Entries Shown
  • Protect heavy duty, right angle terminals in tight or confined spaces
  • Available to fit 8 ga up to 4/0 ga terminals
  • Metric: Fits 8mm2 to 103mm2 terminals
  • Flexible cable entry
  • Available in Red and Black

Battery Case courtesy of MK Battery

Model Cable Opening Terminal Width Terminal Length Rated Size Color
962N9V02 0.42 in 0.77 in 1.18 in 6 AWG Red
962N9V14 0.42 in 0.77 in 1.18 in 6 AWG Black

963N9V02 0.47 in 0.75 in 1.35 in 4 AWG Red
963N9V14 0.47 in 0.75 in 1.35 in 4 AWG Black

964N9V02 0.67 in 0.81 in 1.36 in 2 & 1 AWG Red
964N9V14 0.67 in 0.81 in 1.36 in 2 & 1 AWG Black

965N9V02 0.72 in 0.9 in 1.49 in 1/0 AWG Red
965N9V14 0.72 in 0.9 in 1.49 in 1/0 AWG Black

966N9V02 0.71 in 0.97 in 1.5 in 2/0 AWG Red
966N9V14 0.71 in 0.97 in 1.5 in 2/0 AWG Black

967N9V02 0.87 in 1.08 in 1.51 in 3/0 AWG Red
967N9V14 0.87 in 1.08 in 1.51 in 3/0 AWG Black

968N9V02 0.87 in 1.16 in 1.6 in 4/0 AWG Red
968N9V14 0.87 in 1.16 in 1.6 in 4/0 AWG Black


For quantities under 500 please go to VTE Warehouse
